Nta:
- Desktop tsim, multi-functional lub rooj sib tham chav sib koom ua ke hais lus, yees duab mus txog qhovtwg, kev pabcuam kev sib tham, rooj daim npav zaub thiab kov npo;
- Muaj 300MHz CPU, 512Mb nco, ruaj khov, siv du;
- 4.
- Kev them nyiaj yug 8-inch high-brightness LCD electronic nameplate zaub, tso saib cov ntaub ntawv koom nrog, tso saib kev daws teeb meem ntawm 1280 × 320, txhawb ib daim npav SD renaming lossis khoos phis tawj keeb kwm yav dhau los hloov npe;
- Nrog SD daim npav kaw thiab rov ua haujlwm, txhawb nqa 128 G flash nco, tuaj yeem kaw 2K teev ntawm cov ntsiab lus suab;
- Ua-nyob rau hauv lub rooj sib tham kev pab cuam muaj nuj nqi, txhawb lub rooj sab laj chav tsev xa tshuaj yej, cwj mem thiab ntawv, waiters thiab lwm yam kev thov ceeb toom;
- Nruab nrog 2m 6-core DIN cable nrog cov ntaub thaiv npog kom tsis txhob muaj kev cuam tshuam ntawm electromagnetic cuam tshuam ntawm kab;
- Lub kaw lus txais yuav tus ID chaw nyob, thiab lub rooj sib tham tswj los yog lub rooj sib tham tswj software tuaj yeem hloov kho tus lej ID ntawm chav tsev kom tsis txhob muaj tus lej ID;
- Txais siv cov cuab yeej muaj zog tiv thaiv kev cuam tshuam los xyuas kom meej tias cov khoom siv hauv qhov chaw tsis cuam tshuam los ntawm cov xov tooj ntawm tes, Bluetooth, xov tooj cua, WiFi thiab lwm yam teeb liab;
- Txhawb plaub hom kev ua haujlwm ntawm qhov txwv kom muaj nuj nqis, ua ntej-hauv-tawm-tawm, kev hais lus thiab kev tswj lub suab pib, thiab tus naj npawb ntawm cov neeg hais lus tuaj yeem tsim los ntawm 1 txog 6;
- Nrog lub koob yees duab, tus hais lus tuaj yeem raug taug qab, thiab cov duab khov ua haujlwm tau txais kev txhawb nqa;
- Txhawb peb-tus yuam sij lossis tsib-tus yuam sij pov npav muaj nuj nqi, txhawb kev kos npe rau hauv thiab ntxiv kev kos npe rau hauv kev ua haujlwm, thiab dynamic zaub ntawm cov ntaub ntawv;
- Txais aluminium alloy integrated square microphone qia, ob lub microphone qia thiab ob lub microphone core tsim, thiab txais yuav lub suab cuam tshuam, nrog kev ua tau zoo super-directional;
- Txhawb 48K audio sampling zaus, zaus teb txog 40Hz-20KHz, ze rau CD suab zoo;
- Built-in high-pass lim muaj nuj nqi, yooj yim los txiav tawm qhov tsawg zaus ntawm lub suab thaum xav tau;
- Nruab nrog DSP digital audio processing nti, txhua chav tuaj yeem hloov kho nws tus kheej kom siab thiab qis bass;
- Nrog ob lub 3.5 hli lub mloog pob ntseg ports, nws tuaj yeem siv rau kev saib xyuas kev sib tham thiab kaw, thiab qhov ntim tuaj yeem kho tau;
- Nrog rau ib qho Micro USB cov ntaub ntawv interface, cov cuab yeej tuaj yeem hloov kho thiab khaws cia yam tsis muaj kev cuam tshuam;
- Nws muaj kev ua haujlwm ntawm kev rov ua haujlwm ntawm lub Hoobkas nqi, uas tuaj yeem pib lub suab hloov kho kom tsis txhob muaj suab nrov.
Technical parameters:
|
Qhov system muaj peev xwm |
Ib channel 10 teeb, expandable 51200 teeb |
|
Zaub screen |
4.3 "TFT kov npo, 8.8" LCD zaub |
|
Hom microphone |
Cardioid directivity electret |
|
Teb zaus |
40Hz ~ 20KHz |
|
Teeb liab-rau-nrawm piv |
>90dB ib |
|
Dynamic ntau yam |
96dB ib |
|
Tag nrho harmonic distortion |
< 0.05% |
|
Channel sib cais |
102dB ib |
|
Microphone rhiab heev |
-37dB ± 2dB |
|
Ua haujlwm voltage |
24V DC ± 5% |
|
Ua haujlwm tam sim no |
100mA ± 5% |
|
Unit zog noj |
3W |
|
Sib npaug suab nrov |
20dBA (SPL) |
|
Lub suab siab siab tshaj plaws |
125 dB (THD<3%) |
|
Loj |
152 × 98 × 62mm |
|
Qhov hnyav |
1.15 kg ib |
